材质：UL认证尼龙PA66（可燃性UL 94v-2）
工作温度：-40℃~+100℃
颜色：黑色（RAL9005）、灰色（RAL7035）。可根据要求提供其他颜色。
设计精良的爪，提供与油管的快速安全连接，并获得出色的拔出强度结果，成为电缆保护系统的最佳平衡性能。
| 水密波纹管接头 | ||||
可容纳管道 | 模型 | 螺纹 | AG（mm） 外径 | GL（mm） 螺纹长度 |
| AD10.0 | YKWN-WTF-M12/10 | M12x1.5 | 12 | 9 |
| YKWN-WTF-M16/10 | M16x1.5 | 16 | 10 | |
| AD13.0 | YKWN-WTF-M16/13 | M16x1.5 | 16 | 10 |
| AD15.8 | YKWN-WTF-M16/15.8 | M16x1.5 | 16 | 10 |
| YKWN-WTF-M20/15.8 | M20x1.5 | 20 | 10 | |
| YKWN-WTF-M22/15.8 | M22x1.5 | 22 | 10 | |
| YKWN-WTF-M25/15.8 | M25x1.5 | 25 | 12 | |
| AD18.5 | YKWN-WTF-M16/18.5 | M16x1.5 | 16 | 10 |
| YKWN-WTF-M20/18.5 | M20x1.5 | 20 | 10 | |
| YKWN-WTF-M22/18.5 | M22x1.5 | 22 | 10 | |
| YKWN-WTF-M25/18.5 | M25x1.5 | 25 | 12 | |
| AD21.2 | YKWN-WTF-M20/21.2 | M20x1.5 | 20 | 10 |
| YKWN-WTF-M25/21.2 | M25x1.5 | 25 | 10 | |
| AD25.0 | YKWN-WTF-M20/25 | M20x1.5 | 20 | 10 |
| YKWN-WTF-M25/25 | M25x1.5 | 25 | 10 | |
| AD26.2 | YKWN-WTF-M20/26.2 | M20x1.5 | 20 | 10 |
| YKWN-WTF-M25/26.2 | M25x1.5 | 25 | 10 | |
| AD28.5 | YKWN-WTF-M25/28.5 | M25x1.5 | 25 | 10 |
| AD34.5 | YKWN-WTF-M32/34.5 | M32x1.5 | 32 | 10 |
| AD42.5 | YKWN-WTF-M40/42.5 | M40x1.5 | 40 | 15 |
| YKWN-WTF-M50/42.5 | M50x1.5 | 50 | 15 | |
| AD48.5 | YKWN-WTF-M50/48.5 | M50x1.5 | 50 | 15 |
| AD54.5 | YKWN-WTF-M50/54.5 | M50x1.5 | 50 | 22 |
| YKWN-WTF-M63/54.5 | M60x1.5 | 63 | 25 | |
| 可容纳管道 | 模型 | 螺纹 | AG（mm） 外径 | GL（mm） 螺纹长度 |
| AD10.0 | YKWN-WTF-PG7/10 | PG7 | 12.5 | 9 |
| YKWN-WTF-PG9/10 | PG9 | 15.2 | 9 | |
| AD13.0 | YKWN-WTF-PG11/13 | PG11 | 18.6 | 10 |
| AD15.8 | Y KW N-WTF-PG 13.5/15.8 | PG13.5 | 20.4 | 10 |
| YKWN-WTF-PG16/15.8 | PG16 | 22.5 | 10.8 | |
| AD18.5 | Y KW N-WTF-PG 13.5/18.5 | PG13.5 | 20.4 | 10 |
| YKWN-WTF-PG16/18.5 | PG16 | 22.5 | 10.8 | |
| AD21.2 | YKWN-WTF-PG16/21.2 | PG16 | 22.5 | 13 |
| YKWN-WTF-PG21/21.2 | PG21 | 28.3 | 13 | |
| AD25.0 | YKWN-WTF-PG16/25 | PG16 | 22.5 | 13 |
| YKWN-WTF-PG21/25 | PG21 | 28.3 | 13 | |
| AD26.2 | YKWN-WTF-PG16/26.2 | PG16 | 22.5 | 13 |
| YKWN-WTF-PG21/26.2 | PG21 | 28.3 | 13 | |
| AD28.5 | YKWN-WTF-PG21/28.5 | PG21 | 28.3 | 13 |
| AD34.5 | YKWN-WTF-PG29/34.5 | PG29 | 37 | 13 |
| AD42.5 | YKWN-WTF-PG36/42.5 | PG36 | 47 | 13 |
| AD48.5 | YKWN-WTF-PG42/48.5 | PG42 | 54 | 16 |
| AD54.5 | YKWN-WTF-PG48/54.5 | PG48 | 59.3 | 16 |
可容纳管道 | 模型 | 螺纹 | AG（mm） 外径 | GL（mm） 螺纹长度 |
| AD10.0 | YKWN-WTF-G/NPT1/4-10 | G（NPT）1/4 | 13.1 | 9 |
| AD13.0 | YKWN-WTF-G/NPT3/8-13 | G（NPT）3/8 | 16.6 | 15 |
| AD15.8 | Y KW N-WTF-G/NPT 1/2-15…8 | G（NPT）1/2 | 20.9 | 15 |
| AD18.5 | Y KW N-WTF-G/NPT 1/2-18.5 | G（NPT）1/2 | 20.9 | 15 |
| AD21.2 | Y KW N-WTF-G/NPT 1/2-21.2 | G（NPT）1/2 | 20.9 | 15 |
| Y KW N-WTF-G/NPT 3/4-21.2 | G（NPT）3/4 | 26.4 | 15 | |
| AD25.0 | YKWN-WTF-G/NPT1/2-25 | G（NPT）1/2 | 20.9 | 15 |
| YKWN-WTF-G/NPT3/4-25 | G（NPT）3/4 | 26.4 | 15 | |
| AD26.2 | Y KW N-WTF-G/NPT 1/2-26.2 | G（NPT）1/2 | 20.9 | 15 |
| Y KW N-WTF-G/NPT 3/4-26.2 | G（NPT）3/4 | 26.4 | 15 | |
| AD28.5 | Y KW N-WTF-G/NPT 3/4-28.5 | G（NPT）3/4 | 26.4 | 15 |
| AD34.5 | YKWN-WTF-G/NPT1-34.5 | G（NPT）1 | 33.2 | 15 |
| AD42.5 | Y KW N-WTF-G/NPT 1-1/4-42.5 | G（NPT）1-1/4 | 41.9 | 15 |
| AD54.5 | Y KW N-WTF-G/NPT 1-1/2-54.8 | G（NPT）1-1/2 | 48 | 15 |
| YKWN-WTF-G/NPT2-54.8 | G（NPT）2 | 60 | 15 | |
