材质：SS304/316L
爪：PA66(尼龙)
密封材料：丁腈橡胶(NBR)
O型圈：丁腈橡胶(NBR)
夹芯套筒：A型半通式，B型直通式，C型硅胶式
螺纹尺寸：M螺纹、PG螺纹、G螺纹、NPT螺纹
工作温度：静态-40℃~+100℃，短时可达+120℃。C型可达-50℃~+250℃
防护等级：IP 68
Features:
Excellent Sealing Performance
The soft and elastic silicone material tightly wraps around cables, providing effective protection against water, dust, and gas penetration (commonly rated IP68).
High Temperature & Weather Resistance
Wide operating temperature range (typically -40°C to +200°C), suitable for both extreme heat and cold environments. Resistant to UV radiation and aging.
Chemical Stability
Resistant to oils, acids, alkalis and certain solvents, making it ideal for corrosive environments like chemical plants and petroleum industries.
Vibration Resistance & Anti-Loosening
High friction coefficient of silicone absorbs vibrations and prevents cable movement from causing loosening.
Electrical Insulation
Silicone's inherent insulating properties enhance electrical safety.
| Model | Specification | Clamping Range | AG (mm) | GL (mm) | H (mm) | Wrench Size (mm) |
| YKWS-M8 | M8x1.0 | 2~3.5 | 8 | 6.5 | 15.5 | 12 |
| YKWS-M10 | M10x1.0 | 3~6.5 | 10 | 7 | 19 | 14 |
| YKWS-M12 | M12x1.5 | 3~6.5 | 12 | 7 | 19 | 14 |
| M12x1.5 | 4~8 | 12 | 8 | 21 | 17 | |
| YKWS-M14 | M14x1.5 | 4~8 | 14 | 8 | 21 | 17 |
| YKWS-M16 | M16x1.5 | 3~6.5 | 16 | 8 | 20 | 14/18 |
| M16x1.5 | 4~8 | 16 | 8 | 21 | 17/18 | |
| M16x1.5 | 5~10 | 16 | 8 | 22.5 | 20 | |
| YKWS-M18 | M18x1.5 | 5~10 | 18 | 8 | 22.5 | 20 |
| YKWS-M20 | M20x1.5 | 5~10 | 20 | 8 | 22.5 | 20/22 |
| M20x1.5 | 6~12 | 20 | 8 | 23.5 | 22 | |
| M20x1.5 | 8~14 | 20 | 8 | 23 | 22 | |
| YKWS-M22 | M22x1.5 | 10~14 | 22 | 8 | 23 | 24 |
| M22x1.5 | 10~16 | 22 | 8 | 24.5 | 28 | |
| YKWS-M24 | M24x1.5 | 6~12 | 24 | 8 | 23.5 | 24/27 |
| M24x1.5 | 10~14 | 24 | 8 | 23 | 24/27 | |
| YKWS-M25 | M25x1.5 | 8~14 | 25 | 8 | 23.5 | 24/28 |
| M25x1.5 | 10~16 | 25 | 8 | 24 | 28 | |
| M25x1.5 | 13~18 | 25 | 8 | 26 | 30 | |
| YKWS-M27 | M27x2.0 | 10~16 | 27 | 9 | 24.5 | 28/30 |
| M27x2.0 | 13~18 | 27 | 9 | 26 | 30 | |
| YKWS-M30 | M30x2.0 | 10~16 | 30 | 9 | 24.5 | 28/34 |
| M30x2.0 | 13~18 | 30 | 9 | 26 | 30/34 | |
| YKWS-M32 | M32x1.5 | 13~18 | 32 | 9 | 26 | 30/36 |
| M32x1.5 | 15~22 | 32 | 9 | 28 | 36 | |
| M32x1.5 | 18~25 | 32 | 9 | 33 | 40 | |
| YKWS-M33 | M33x2.0 | 15~22 | 33 | 9 | 33 | 40 |
| YKWS-M36 | M36x2.0 | 15~22 | 36 | 9 | 28 | 36/40 |
| M36x2.0 | 18~25 | 36 | 9 | 33 | 40 | |
| YKWS-M37 | M37x2.0 | 18~25 | 36 | 9 | 33 | 40 |
| YKWS-M40 | M40x1.5 | 18~25 | 40 | 10 | 33 | 40/45 |
| M40x1.5 | 22~30 | 40 | 10 | 35.5 | 45 | |
| M40x1.5 | 22~30 | 40 | 10 | 38.5 | 50 | |
| YKWS-M42 | M42x2.0 | 22~30 | 42 | 10 | 38.5 | 50 |
| YKWS-M47 | M47x2.0 | 25~33 | 48 | 10 | 38.5 | 50/52 |
| YKWS-M48 | M48x2.0 | 25~33 | 48 | 10 | 38.5 | 50/52 |
| YKWS-M50 | M50x2.0 | 22~30 | 50 | 10 | 38.5 | 55 |
| M50x2.0 | 32~38 | 50 | 11 | 40 | 55/58 | |
| YKWS-M54 | M54x2.0 | 32~38 | 50 | 11 | 40 | 58/60 |
| YKWS-M60 | M60x2.0 | 37~44 | 60 | 11 | 41.5 | 65 |
| Model | Specification | Clamping Range | AG (mm) | GL (mm) | H (mm) | Wrench Size (mm) |
| YKWS-M63 | M63x1.5 | 37~44 | 63 | 11 | 41.5 | 65/70 |
| M63x1.5 | 42~53 | 63 | 11 | 44 | 75 | |
| YKWS-M64 | M64x2.0 | 37~44 | 64 | 11 | 41.5 | 65/70 |
| M64x2.0 | 42~53 | 64 | 11 | 44.5 | 75 | |
| YKWS-M72 | M72x2.0 | 37~44 | 72 | 11 | 44.5 | 80 |
| M72x2.0 | 42~52 | 72 | 13 | 44.5 | 80 | |
| M72x2.0 | 55~61 | 72 | 24 | 57 | 86 | |
| YKWS-M75 | M75x2.0 | 37~44 | 75 | 14 | 57 | 86 |
| M75x2.0 | 42~52 | 75 | 13 | 44.5 | 86 | |
| YKWS-M76 | M76x2.0 | 55~61 | 76 | 25 | 57 | 86 |
| YKWS-M80 | M80x2.0 | 55~62 | 80 | 13 | 47 | 86 |
| M80x2.0 | 42~53 | 80 | 13 | 57 | 86 | |
| M80x2.0 | 65~75 | 80 | 13 | 58 | 96 | |
| M80x2.0 | 55~61 | 80 | 25 | 47 | 86 | |
