材质：SS304/316L/镀镍黄铜
爪：PA66(尼龙)
密封材料：丁腈橡胶(NBR)
O型圈：丁腈橡胶(NBR)
螺纹尺寸：M螺纹、PG螺纹、G螺纹、NPT螺纹
工作温度：静态-40℃~+100℃，短时可达+120℃。
防护等级：IP 68
无数据
| Model | Specification | Clamping Range | AG (mm) | GL (mm) | H(mm) | Wrench Size (mm) |
| YKWS/B-BR-M12 | M12x1.5 | 3~6.5 | 12 | 7 | 27 | 17 |
| YKWS/B-BR-M14 | M14x1.5 | 4~8 | 14 | 7 | 27 | 19 |
| YKWS/B-BR-M16 | M16x1.5 | 4~8 | 16 | 7 | 27 | 21 |
| YKWS/B-BR-M18 | M18x1.5 | 5~10 | 18 | 8 | 29 | 22 |
| YKWS/B-BR-M20 | M20x1.5 | 6~12 | 20 | 8 | 32 | 24 |
| YKWS/B-BR-M22 | M22x1.5 | 10~14 | 22 | 8 | 32 | 27 |
| YKWS/B-BR-M25 | M25x1.5 | 10~16 | 25 | 9 | 35 | 27 |
| YKWS/B-BR-M27 | M27x1.5 | 13~18 | 27 | 9 | 35 | 30 |
| YKWS/B-BR-M28 | M 28x1.5 | 13~18 | 28 | 9 | 45 | 30 |
| YKWS/B-BR-M30 | M 30x1.5 | 13~18 | 30 | 10 | 50 | 36 |
| YKWS/B-BR-M32 | M32x1.5 | 15~22 | 32 | 10 | 50 | 38 |
| YKWS/B-BR-M37 | M37x1.5 | 18~~25 | 37 | 12 | 54 | 42 |
| YKWS/B-BR-M40 | M40x1.5 | 22~30 | 40 | 12 | 55 | 46 |
Note: According to customer installation requirements, thread length GL extension and thread customization can be provided
